SKU: G2236CLD9-INT

Clear 9 Lite Glass and Frame Kit (Interior 1 3/8" Door Thickness - Half Lite)

$119.00 $200.00

Frame size
Glass type
In stock
Description

Door Glass and Frame Kit

New door glass can transform an interior door or bring life to an entryway without the need to replace your entire door system. This is a great option to add glass to an existing door slab or to add glass to one of our interior doors. It is also a great replacement for 1 3/8" exterior doors, such as mobile home doors.

Kit includes door glass, inside and outside door glass frame set, screws, and screw caps.

KIT IS FOR INTERIOR DOORS OR DOORS THAT ARE 1 3/8" THICK - THE STANDARD ENTRY DOOR VERSION OF THIS PRODUCT FOR 1 3/4" THICK DOORS CAN BE FOUND HERE

Easy Installation

Our kit makes installation easy and quick. After cutting out your door (if needed) with a circular saw or jigsaw, all you need to install the glass kit into your door is a screwdriver to secure the inside frame to the outer frame. Please double check that the cut dimensions below with align with the panels on your door. If you intend to install into an interior door that you are purchasing from us, please contact us and we'll make sure you order the correct size. Also, we do not recommend cutting out hollow core interior doors, as significant reinforcement will be needed to support the weight of this glass kit. If you do have a hollow core door, we recommend upgrading to one of our interior doors.

Single Pane Safety Glass

Single pane insulated glass has been tempered for safety

High Performance Frame

Kit includes standard white high performance plastic frames that resist cracking, warping, and discoloring due to heat and sunlight. Standard white frames are ready to install and do not need to be painted, but can be painted after lightly sanding and priming.

Dimensions

Style: Half Lite (rectangular)

Standard Size:

  • Frame outside dimensions: 24" x 38" (replaces frames 23 1/2" to 24" wide and 37 1/2" to 38" tall)
  • Door cutout dimensions: 23" x 37" (typically works with 32", 34" and 36" wide interior doors)
  • Glass dimensions: 1/8" thick, 22" wide, 36" tall

Narrow Size:

  • Frame outside dimensions: 22" x 38" (replaces frames 21 1/2" to 22" wide and 37 1/2" to 38" tall)
  • Door cutout dimensions: 21" x 37" (typically works with 28" and 30" wide interior doors)
  • Glass dimensions: 1/8" thick, 20" wide, 36" tall
