SKU: G2248CLD4

Clear 4 Lite Glass and Frame Kit (3/4 Lite 24" x 50" Frame Size)

$299.00

Measure plastic frame width and height (outer edge). More on how to measure.

Frame size
Glass type

Backordered - typically returns to stock in 5-10 days

Description

Door Glass and Frame Kit

New door glass can transform your entryway without the need to replace your entire door system. Classic 4 lite style with external grids.

Kit includes door glass, inside and outside door glass frame set, screws, and screw caps.

Measurements

Style: 3/4 Lite (rectangular)

  • Frame outside dimensions: 24" x 50" (replaces frames 23 1/2" to 24" wide and 49 1/2" to 50" tall) PLEASE MAKE SURE YOUR FRAMES ARE NO MORE THAN 50 1/8" TALL (best to measure frame on inside of home if exterior frame is cracked/warped).
  • Door cutout dimensions: 23" x 49"
  • Glass dimensions: 1/2" thick, 22" wide, 48" tall
Easy Installation

Our kit makes installation easy and quick. The outside frame comes pre-caulked to the glass. All you need to install the glass kit into your door is a screwdriver to secure the inside frame to the outer frame. Cover the screw heads with the included plastic caps, paint or stain if desired, and your project is finished! More on installation

Insulated Safety Glass (Low-E by special order)

Glass has been tempered for safety and thermally sealed to be air and water tight.

Low-E glass available by special order. We recommend Low-E for applications where energy efficiency is needed, for example in areas with cold winters/hot summers (especially if the door receives direct sunlight). Pleasecontact usfor pricing and to place the order.

High Performance Frame (Paint/Stain)

Comes standard with high quality vinyl frames. Frames can be painted or stained without a primer. More on finishing door glass frames

Cleaning

Avoid contact with abrasive cleaners and solutions containing corrosive solvents or acid solutions. Glass can be cleaned using a soft cloth, and glass cleaner.
