SKU: G2236VE

Venting 1 Lite Glass and Frame Kit (Half Lite 24" x 38" Frame Size)

$199.00 $249.00

Measure plastic frame width and height (outer edge). More on how to measure.

Frame size
Glass type
In stock

Door Glass and Frame Kit

Venting door glass is a great option for kitchen doors or any area where you want the option to let in a nice breeze. Our venting door glass features a removeable screen and 10 height adjustments to allow for desired airflow.

Kit includes door glass, removeable screen, inside and outside door glass frame set, screws, and screw caps.


Style: Half Lite (rectangular)

  • Frame outside dimensions: 24" x 38" (replaces frames 23 1/2" to 24" wide and 37 1/2" to 38" tall)
  • Door cutout dimensions: 23" x 37"
  • Glass dimensions: 3/4" thick, 22" wide, 36" tall


CAUTION: RAISE the lower sash (white lever raises sash) before installing the kit into the door. Pinching the latches under the frame can damage the kit.

Venting Door Glass Lever Closeup

Install frames with the screws to the inside of the home. Tighten screws until frame is seated on the door. Do not exceed 15 in-lbs of torque. Over-tightening screws may result in a wavy appearance of the frame. Finish by installing screw hole covers (caps) by inserting the shallow edge of cover into the frame aligning with the frame profile. Press firmly into place, making sure the cover is flush with the profile.

Easy Installation

Our kit makes installation easy and quick. The outside frame comes pre-caulked to the glass. All you need to install the glass kit into your door is a screwdriver to secure the inside frame to the outer frame. Cover the screw heads with the included plastic caps, paint or stain if desired, and your project is finished! More on installation

Insulated Safety Glass

Double pane insulated glass has been tempered for safety and thermally sealed to be air and water tight.

High Performance Frame

Kit includes standard white high performance plastic frames thatresist cracking, warping, and discoloring due to heat and sunlight. Your white frame is maintenance free, does not require paint, and will not yellow. Due to the design, we recommend you do not paint this frame.


Avoid contact with abrasive cleaners and solutions containing corrosive solvents or acid solutions. Glass can be cleaned using a soft cloth, and glass cleaner.
